Bare Fiber Testing Lc To St Fiber Adapterr Metal Round Type Precise Connecting

Name: Bare Fiber Testing Lc To St Fiber Adapterr Metal Round Type Precise Connecting
Brand: sunwise
Price: 1 USD

Brand Name : sunwise

Model Number : SC Bare Fiber Optic Adapter Used for Bare Fiber Testing

Place of Origin : china

MOQ : Negotiable

Price : Negotiable

Payment Terms : Western union,T/T,PayPal

Supply Ability : 1 million km / month for fiber optic cables; 200,000 pcs / month for patch cords;100,000 PCS / month for equipment

Delivery Time : jumper 3 ~ 7 days; fiber optic cable and equipment 7 ~ 15 days

Packaging Details : jumper 63 * 63 * 45 ; carton equipment / optical cable,carton + wooden optical cable shaft

Product name : fiber optic adapter

Color : Blue /Beige /Green

Insertion loss : ≤ 0.2dB(SM&MM)

Application : FTTH FTTB FTTX Network

Certification : ISO9001,RoHS,CE

Operating temperature : -40℃ to 85℃

Contact Now

Bare Fiber Testing Lc To St Fiber Adapterr Metal Round Type Precise Connecting

Description
Round type SC Bare Fiber Optic Adapter is used for emergency repairs of fiber optic cable and temporary fiber connection and fiber optic cable fast test.
It can link bared optic and light source, testing equipment, light appearance, etc.
SC Bare Fiber Adapter is used for test appearance and temporary conjunction between fiber optics extensively (repair fiber optic cable urgently).
Such SC bare fiber optic adapters can square and round types optional.

Specification
Stable capability and high reliability
Precise connecting
Outstanding Mechanical characters
Human-centered Design
Simple to use
Suitable for fiber with coating diameters of 250um & 900um

Application
Emergency repairs of fiber optic cable, temporary fiber connection and fiber optic cable fast test.
Comply with Rosh directive and other industrial standard
Bare Fiber Connection
Local Area Networks and Telecommunication Networks
Fiber optic testing, fiber optic cable repair

Technical Parameter

Parameter	Unit	LC, SC, FC, ST
		SM			MM
		PC	UPC	APC	PC
Insertion Loss (Typical)	dB	≤0.3	≤0.2	≤0.3	≤0.2
Return Loss	dB	≥45	≥50	≥60	≥30
Exchangeability	dB	≤0.2
Repeatability	dB	≤0.2
Durability	Time
Operating Temperature	°C	-40~75
Storage Temperature	°C	-45~85
Plug and Unplug force (g/f)		200~600
Spec		Simplex

Bare Fiber Testing Lc To St Fiber Adapterr Metal Round Type Precise Connecting

FAQ
Q1. Do you provide sample service?
A: Yes, we provide free or low price samples for you to test and check quality. Mixed samples are acceptable.
Q2. What about the MOQ?
A: Most products have a minimum order quantity, but some stocks can accept small orders.
Q3. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT international express service. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q4: How long is the guarantee of the product?
A: According to the type of product,We offer 1-3 years warranty to our formal products.
Q5: What about delivery time?
A: We need 1-3 days to handling the sample, and 5-15 days to process our normal goods.
